Image Registry Lab¶

40 min Intermediate

In the Containers Lab you pushed the greeting image to Quay.io. In this lab you'll run that image on OpenShift, pull it from a private repository with a pull secret, and then build the image inside the cluster and store it in OpenShift's internal registry.

Prerequisites¶

• You've finished the Containers Lab, and quay.io/<your-username>/greeting:v1.0.0 exists and is public. If you built it on an Apple Silicon Mac, build it for linux/amd64 (or multi-arch), as described at the end of that lab.
• You're logged in to an OpenShift cluster with oc. See lab environment options.
• You still have the greeting directory with main.go, go.mod and Containerfile.

export QUAY_USER=<your-username>
oc new-project registry-lab

Part 1: Deploy an image from a public registry¶

1. Create a Deployment named greeting from your Quay image, with container port 8080.

   Solution

   oc create deployment greeting --image=quay.io/${QUAY_USER}/greeting:v1.0.0 --port=8080
   oc rollout status deployment/greeting


2. Expose the Deployment as a Service, then expose the Service as a Route.

   Solution

   oc expose deployment greeting --port=8080
   oc expose service greeting


3. Call the app through its Route:

   curl "http://$(oc get route greeting -o jsonpath='{.spec.host}')/greeting?name=OpenShift"


   {"message":"Welcome to the Cloud Native Bootcamp!","name":"OpenShift"}


Part 2: Pull from a private repository¶

Most company images live in private repositories. The cluster needs credentials, a pull secret, to download them.

1. On quay.io, open the greeting repository, go to Settings, and make it private.

2. Force a new pull by restarting the Deployment. The new pod fails to start. Find out why.

   Solution

   oc rollout restart deployment/greeting
   oc get pods
   oc describe pod -l app=greeting | grep -A 5 Events


   The new pod shows ErrImagePull / ImagePullBackOff, with an unauthorized error in the events. The old pod keeps serving traffic, because the rolling update never removes the working pod before its replacement is ready.

3. Create a robot account with read access to the repository:

   1. In Quay, open Account Settings > Robot Accounts and create a robot account, for example openshift_puller.
   2. Give it Read permission on the greeting repository.
   3. Open the robot account and copy its username (<your-username>+openshift_puller) and token.

   Robot accounts are better than your personal password: each one is scoped to specific repositories and can be revoked on its own.

4. Create a pull secret named quay-pull from the robot credentials, and link it to the default ServiceAccount for pulling images.

   Solution

   oc create secret docker-registry quay-pull \
     --docker-server=quay.io \
     --docker-username="${QUAY_USER}+openshift_puller" \
     --docker-password='<robot-token>'
   oc secrets link default quay-pull --for=pull


   oc secrets link adds the secret to the ServiceAccount's imagePullSecrets. Every pod that runs as that ServiceAccount can then pull with it. You could also list the secret under spec.imagePullSecrets in each Pod template.

5. Delete the failing pod so it's recreated with the pull secret, and check that the rollout completes.

   Solution

   oc delete pod -l app=greeting --field-selector=status.phase=Pending
   oc rollout status deployment/greeting


Part 3: Build inside the cluster¶

OpenShift can build images itself, without Podman on your laptop and without an external registry. A BuildConfig describes the build. The result goes into the cluster's internal registry, where an ImageStream tracks it.

1. From inside your greeting directory, create a binary build named greeting-internal that uses your Containerfile.

   Solution

   cd greeting
   oc new-build --name=greeting-internal --binary --strategy=docker


   --binary means the source is uploaded from your machine when the build starts, not cloned from Git.

2. Start the build, upload the current directory, and follow the build log.

   Solution

   oc start-build greeting-internal --from-dir=. --follow


   The log ends with Push successful. The image was pushed to image-registry.openshift-image-registry.svc:5000/registry-lab/greeting-internal.

3. Look at the ImageStream that tracks the image.

   Solution

   oc get imagestream greeting-internal
   oc describe imagestream greeting-internal


4. Deploy the image from the ImageStream with a custom greeting, and expose it.

   Solution

   oc new-app greeting-internal --name=greeting-internal -e GREETING="Built on OpenShift"
   oc expose service greeting-internal
   curl "http://$(oc get route greeting-internal -o jsonpath='{.spec.host}')/greeting"


   {"message":"Built on OpenShift","name":"World"}


   oc new-app creates a Deployment and a Service. Because the Deployment uses an ImageStream tag, a later build automatically rolls out the new image.

Cleanup¶

oc delete project registry-lab

What you learned¶

• Deploying and exposing an image from a public registry
• Pulling from private registries with robot accounts and pull secrets
• Building images in-cluster with BuildConfigs, ImageStreams and the internal registry
